SGMG-05V2AB servo encoder

SGMG-05V2AB servo encoder

Product Details Introduction

SGMG-05V2AB is equipped with a high-resolution optical detection module, with a positioning accuracy of ± 3 μ m, meeting the requirements of precision control

Suitable for 200V three-phase servo system, seamlessly compatible with 450W level servo motor, with precise signal transmission

SGMG-05V2AB outputs RS422 differential signal, with strong anti-interference ability and stable transmission in complex industrial environments

Response frequency up to 1MHz, suitable for high-speed motors above 3000rpm, dynamic tracking without delay

Protection level up to IP65, dustproof and waterproof splash design, suitable for humid and dusty industrial sites

SGMG-05V2AB adopts an incremental encoding structure, with stable pulse signals and strong real-time position feedback

The shell is made of corrosion-resistant alloy material, with surface anodizing treatment, and excellent resistance to salt spray erosion

Shaft diameter compatible with 14mm standard servo motor output shaft, precise installation and positioning, easy disassembly and assembly

SGMG-05V2AB supports 24V DC power supply and has a power consumption as low as 1.2W, with outstanding energy-saving performance

Equipped with signal fault self diagnosis function, timely feedback of wire breakage and short circuit abnormalities, improving system reliability

Compatible with Yaskawa Sigma series servo drives, with strong communication protocol compatibility and low integration cost

SGMG-05V2AB operates within a temperature range of -10~60 ℃, with a wide temperature range suitable for industrial scenarios in multiple regions

Excellent long-term stability of coding accuracy, with an annual drift of ≤± 0.5 μ m, reducing calibration frequency

Supports bidirectional positioning detection in both forward and reverse directions, compatible with reciprocating motion equipment, and has no deviation in direction recognition

SGMG-05V2AB has passed CE and VDE international certifications, ensuring worry free compliance and suitability for global industrial applications

SGMG-05V2AB Product imag
