DFY112LB/TH servo motor

 DFY112LB/TH servo motor

Product Details Introduction

DFY112LB/TH adopts a permanent magnet synchronous motor design, with a rated power of up to 3.0kW, a rated torque of 19.1N · m, and a wide speed range of 0-3000rpm, suitable for medium and high-power precision drive scenarios

Equipped with high-precision incremental encoder, with a resolution of 17 bits (131072 pulses/rev) and a positioning accuracy of ± 0.01 °, ensuring precise positioning and trajectory control of industrial equipment

Supports dual methods of flange installation and base fixation, with a standard flange size of 112mm, suitable for installation layouts of various machine tools and automation equipment, and high installation flexibility

The protection level of DFY112LB/TH reaches IP65, and the metal shell has dustproof and waterproof characteristics, which can be directly deployed in multi dust working conditions such as mechanical processing and automated production lines

Compatible with mainstream industrial communication protocols such as Modbus, EtherCAT, Profinet, etc., smoothly linked with PLC and motion controllers, with data transmission latency as low as 1ms

Working temperature coverage -10 ℃~+60 ℃, humidity tolerance 0~95% (no condensation), equipped with F-class insulation design, suitable for high and low temperature fluctuation environment in industrial sites

DFY112LB/TH has multiple protections such as overload protection, overcurrent protection, and overheating protection. It can withstand 150% rated torque overload for 60 seconds, ensuring safe operation of the motor and load

Adopting sine wave vector control technology, the low-speed operation is smooth without shaking, and the low-speed torque fluctuation is ≤± 5%, meeting the low-speed feed requirements of precision equipment

The power supply voltage is suitable for three-phase AC 220V/380V, with a voltage fluctuation tolerance of ± 10%. It has strong ability to cope with industrial power grid fluctuations and does not require additional voltage stabilizing devices

DFY112LB/TH supports position mode, speed mode and torque mode switching, which can be freely configured through parameters to adapt to different process control requirements

The motor body is made of high-strength aluminum alloy material, which is lightweight and has excellent heat dissipation performance. The continuous operating temperature rise is ≤ 80K, extending the service life

Built in electromagnetic braking function, braking response time ≤ 20ms, quickly locks the shaft after power failure to prevent load sliding and improve equipment operation safety

 DFY112LB/TH servo motor Product imag
