Product Details Introduction

1746-BAS-T module introduction

1746-BAS-T is a BASIC language intelligent module of the Rockwell Allen Bradley SLC 500 series, not an analog output module. The following is a detailed introduction:

Belonging to the SLC 500 series programmable intelligent processing module, equipped with BASIC programming environment

The core functions include performing custom operations, data processing, serial communication, and protocol conversion

Equipped with 24KB battery backup RAM, supporting program and data power-off saving

Built in real-time calendar clock, providing timestamp and timing functions

Equipped with three communication ports, supporting RS-232/422/485 and DH-485 networks

Dual isolation serial port can connect third-party devices such as instruments, barcode guns, frequency converters, etc

Bidirectional data exchange with SLC main CPU through data words

Multiple LED indicator lights on board, displaying real-time operation, fault, and communication status

Adopting electrical isolation design to effectively enhance the anti-interference ability of industrial environment

Installed in SLC 500 standard 1746 rack slot, compatible with multiple CPU models

Low backplane power consumption, suitable for long-term stable operation

The working temperature range meets the requirements of harsh environments in industrial sites

Program download, online monitoring, and debugging can be performed through serial port

This model has been discontinued, and the market is dominated by second-hand, refurbished, and repair spare parts

If analog output function is required, SLC 500 dedicated analog output module should be selected

In summary, 1746-BAS-T is an intelligent co processing module of SLC 500 system, focusing on complex logic and communication expansion, and does not have analog output function. The actual selection needs to match the corresponding I/O module according to control requirements.

1746-BAS-T Product imag
