Product Details Introduction

1746-HSRV motion control module introduction

1746-HSRV is a Rockwell SLC 500 series dedicated servo motion control module used for single axis high-precision closed-loop motion control. The following is a detailed introduction:

Belonging to the SLC 500 platform dedicated single axis servo control module

Supports three closed-loop control modes: position, speed, and torque

Compatible with SLC 5/03, 5/04, 5/05 series CPU processors

Support incremental A/B/Z phase encoder signal feedback

Equipped with 32-bit high-precision position counting function

Output ± 10V analog signal to drive servo driver

Support absolute positioning, relative positioning, and speed operation modes

Built in multiple origin regression modes for easy device calibration

Independent motion data interaction with CPU through data words

Onboard LED indicator lights display running, fault, and encoder status

Installed in SLC 500 standard 1746 rack slot

Powered by 5V DC from the backplane, no additional external power supply required

Equipped with protection functions such as encoder disconnection, position deviation, overload, etc

Widely used in precision equipment such as positioning, cutting, packaging, etc

This model has been discontinued, and the market mainly consists of second-hand and refurbished spare parts

In summary, 1746-HSRV is the core module of SLC 500 system for achieving precision servo motion control. It relies on encoder feedback and analog output to achieve stable closed-loop control and is an important spare part for old automation equipment.

1746-HSRV Product imag
