0010-61697 Magnet Component

0010-61697 Magnet Component

Product Details Introduction

0010-61697 Magnet Component Core Product Features

1. High magnetic energy product and strong magnetic output: 0010-61697 adopts high-end neodymium iron boron permanent magnet material, with a maximum magnetic energy product of 30-55MGOe, which is more than 10 times that of ordinary ferrite magnets. It can generate a super strong magnetic field with a small volume and is suitable for precision driving scenarios.

2. Wide temperature range stable operation: The working temperature covers -40 ℃~150 ℃, and the magnetic performance attenuation in extreme environments is less than 5%. The optional samarium cobalt material version (temperature resistance up to 350 ℃) is suitable for industrial high-temperature workshops and outdoor low-temperature scenarios.

3. Precision machining with precise dimensions: The dimensional tolerance is controlled within ± 0.005mm, and the verticality error is ≤ 0.01mm. It supports customized shapes such as circular and block shapes, meeting the installation requirements of space limited equipment such as micro motors and sensors.

4. Multiple anti-corrosion and wear-resistant protection: The surface is treated with zinc nickel coating, chemical nickel or poly (p-xylene) encapsulation, and can withstand salt spray testing for more than 500 hours. It has excellent corrosion and wear resistance and is suitable for complex environments such as marine and chemical industries.

5. High anti demagnetization performance: intrinsic coercivity ≥ 955kA/m, optimized by special alloy and microstructure design, strong anti vibration and anti external magnetic field interference ability, with a service life of over 10 years.

6. Multi polarization magnetization adaptation: Supports axial unipolar, radial multi-stage, and composite magnetization methods, with uniform magnetic flux density, and can accurately match the magnetic field requirements of different working conditions such as proximity switches and motor rotors.

7. Safety and compliance design: The magnetic flux index complies with CPSC safety standards, avoiding the risk of accidental ingestion of small parts, while meeting RoHS environmental requirements, and no harmful substances are released.

8. High energy conversion efficiency: The energy conversion efficiency exceeds 90%, and when used with a motor, it can save more than 30% of energy, significantly improving the device's endurance and adapting to energy-saving scenarios such as humanoid robots and new energy vehicles.

9. Modular integration design: Supports the combination and assembly of multiple magnets, customizable magnetic field strength and distribution according to requirements, compatible with automated production line installation processes, and easy integration.

10. Wide adaptability to multiple scenarios: Compliant with relevant industry standards such as IEC and ISO, suitable for industrial automation, humanoid robot joint motors, new energy vehicle power components, explosion-proof proximity switches, and other applications in multiple fields.

0010-61697 Product imag
