BS112A.00.210E.00 servo motor

BS112A.00.210E.00 servo motor

Product Details Introduction

1、 Core positioning

The Mavilor series AC servo motors under the Spanish company Infineon are designed to provide high-precision torque and speed control for industrial equipment, with a focus on compact structure and stable operating performance

Brand: Infranor Mavilor (originally from Spain), adaptation system: compatible with mainstream industrial motion control systems, standard adaptation Infranor A4S series servo drive (model A4S-0750)

Product status: Second hand tested qualified parts and refurbished parts are the mainstream supply form, third-party channels have sufficient stock (weekly supply can reach 10 units), and some suppliers provide a 3-month warranty service

2、 Key parameters

Power performance: Designed with three-phase AC power supply, suitable for medium power industrial scenarios. Specific rated power, speed, and current parameters should be based on the equipment nameplate (the rated power of the same series models covers the range of 1.5-3.0 kW)

Structural specifications: Compact design, weighing about 6kg, using standard flange installation dimensions, suitable for the narrow installation space of industrial equipment, and the shell is made of industrial grade protective material

Interface and Feedback: Equipped with standard servo motor wiring terminals, supporting incremental/absolute encoder feedback (recommended with 2500 line incremental encoder), signal interface compatible with mainstream driver communication protocols

Protection and Environment: The protection level meets the IP54 industrial standard, the working temperature is -10 ℃~60 ℃, the relative humidity is ≤ 90% (no condensation), and the anti electromagnetic interference performance meets the general industrial EMC standards

3、 Core functions and applications

Core functions: support position, speed and torque control, fast dynamic response, small torque fluctuation, low operating noise, and adapt to high-frequency start stop and precise positioning scenarios

Application scenarios: Industrial robot joint drive, CNC machine tool feed axis control, automatic assembly line execution mechanism, precision packaging machinery and other equipment that require high control accuracy, widely used in industries such as electronic manufacturing and automotive parts processing

BS112A.00.210E.00  Product imag
