Product Details Introduction

Installing Festo EMMS-AS-100-S-HS-RRB requires a 100 × 100mm flange bracket with a fixed torque of 120-150N · cm to avoid axial force on the shaft end.

Before wiring, confirm that the power supply voltage matches the rated 565VDC of EMMS-AS-100-S-HS-RRB to prevent overvoltage damage to the winding.

This model supports position/speed/torque three mode control and needs to be matched with Festo CMMS series driver configuration parameters.

The encoder signal line and power cable should be routed separately, and the M23 connector should be securely fastened to ensure Endat communication stability.

Regularly clean the EMMS-AS-100-S-HS-RRB casing with a dry cloth to prevent dust and splashing liquids from entering the IP54 protection.

The operating environment temperature should be controlled between -40 ℃ and+40 ℃. If the temperature exceeds the limit, the capacity should be reduced by 1.5%/℃.

When releasing the brake, first energize the brake coil and then start Festo EMMS-AS-100-S-HS-RRB to avoid accidental load movement.

The motor shaft should be kept dry and free of oil stains. When installing the coupling, it is forbidden to knock the shaft end to protect the feather key structure.

Every 12 months, check the insulation resistance of the winding to be ≥ 5M Ω, and verify whether the PTC temperature monitoring function is normal.

Before restarting after being idle for more than 6 months, manually rotate the shaft to check its flexibility, preheat it for 30 minutes without load, and then run it with load.

Summary: The stable operation core of Festo EMMS-AS-100-S-HS-RRB servo motor lies in standardized installation, communication protection, correct operation of the brake, and environmental adaptation. Relying on the advantages of 1.5kW power, 3.24Nm rated torque, and IP54 protection, combined with compliant maintenance, it can fully exert its precision control performance and ensure reliable operation of the automation system.

EMMS-AS-100-S-HS-RRB Product imag
