NTAI02 Analog Input Terminal Unit

NTAI02 Analog Input Terminal Unit

Product Details Introduction

NTAI02 Analog Input Terminal Unit

-Specially designed for ABB industrial control systems, focusing on analog signal acquisition and transmission, adapting to various types of sensor signals such as temperature and pressure.

-Supports 16 differential analog input channels, compatible with 4-20mA and 0-10V standard signals, and suitable for the vast majority of industrial analog sensors.

-The measurement accuracy reaches ± 0.1% FS, with a sampling rate of up to 100Hz, ensuring accurate capture and real-time transmission of weak analog signals.

-Integrated high-precision signal conditioning circuit with signal filtering and amplification functions, effectively suppressing noise interference and improving signal purity.

-Adopting DC24V rated power supply, with a power consumption as low as 2.5VA, it is suitable for centralized power supply systems in industrial sites, energy-saving and highly stable.

-The protection level reaches IP54, dustproof and splash proof, and can be directly applied to non explosion proof and harsh industrial sites such as workshops.

-Each input channel has an independent electrical isolation design, with an isolation voltage of up to 1500V AC, to avoid interference between channels and grounding loop problems.

-The working temperature ranges from -25 ℃ to+70 ℃, and it can withstand low temperature, humid and hot working conditions, suitable for the anti freezing needs of industrial production in winter.

-Integrated standard communication interface, compatible with ABB proprietary protocols, can seamlessly integrate with DCS systems to achieve data uploading and instruction interaction.

-Equipped with channel status indicator lights, it provides real-time feedback on signal acquisition status, quickly locates faulty channels in case of abnormalities, and facilitates troubleshooting.

-Adopting a guide rail installation design, the structure is compact and does not take up space. It can be coordinated with other ABB modules for easy installation.

-Supporting online calibration function, precision calibration can be completed without disassembling the module, significantly reducing on-site operation and maintenance costs.

-Through CE and IEC industrial standard certification, it complies with global industrial safety regulations and can be widely used in industries such as power and chemical.

-Using screw terminal wiring, the connection is firm and anti loose, matched with clear channel identification, simplifying the wiring and debugging process.

-Built in overvoltage and overcurrent protection circuits effectively protect sensors and module core components, extending the service life of equipment.

NTAI02 Product imag

NTAI02 ontroller Module
