Product Details Introduction

IMEC11 controller module product features (15 items)

1. 8 analog input channels, compatible with 4-20mA passive and 1-5VDC active signals, directly connected to industrial sensors without the need for conversion modules.

2. A 12 bit successive approximation AD converter with self calibration, with a measurement accuracy of ± 0.1% FS, and superior recognition of small signals compared to similar products.

3. FSK high-frequency communication (9600bps), Ethernet+RS485 dual interface redundancy, adapt to different transmission scenarios.

4. Triple isolation of input/output/power supply (1500VAC), effectively resisting interference from industrial sites.

5. 24VDC wide voltage power supply (19.2-28.8VDC), with dual protection against reverse connection and overvoltage.

6. Operating at a wide temperature range of -40 ℃ to 85 ℃, with a high-temperature performance degradation of ≤ 5%, suitable for extreme working conditions.

7. 250 ohm standard input impedance, signal response delay ≤ 100ms, ensuring control timeliness.

8. 256KB high-speed cache, supporting data loop storage and breakpoint retransmission to avoid data loss.

9. Dual color LED indicator provides intuitive feedback on operation, communication status, and fault types, making maintenance and operation convenient.

10. Compatible with ABB systems, modular design can be directly embedded into existing control cabinets, and upgrades do not require logic reconstruction.

11. IP30 protection+B-class insulation material, resistant to industrial level 2 pollution environment, dustproof and moisture-proof.

12. Support remote calibration and debugging of the upper computer, without the need to disassemble modules, reducing maintenance costs.

13. Net weight 499g, DIN rail installation, compact structure suitable for dense layout of control cabinets.

14. Adaptive filtering circuit to suppress high-frequency interference and ensure stable and consistent data.

15. Through UL and CE certification, it meets multiple industry standards and has a wide range of application scenarios.

IMEC11   Product imag

IMEC11  ontroller Module
