IMDSI12 Digital Input Module

IMDSI12 Digital Input Module

Product Details Introduction

IMDSI12 Digital Input Module Product Features (15)

1. Configure 12 independent digital input channels, support 24/48/125VDC and 120VAC multi voltage specifications, and adapt to a wider range of scenarios.

2. Equipped with a fixed 17 millisecond debounce filter, it can effectively suppress mechanical switch jitter and ensure signal acquisition stability.

3. Support manual configuration of working voltage and AC/DC mode using jumper cables, with flexible operation and adaptability to different on-site signal requirements.

4. Compatible with ABB INFI 90 open system, can directly replace IMDSI02 module (after jumper matching), upgrade without changing the architecture.

5. The channel and backplane bus are designed with optoelectronic isolation, with an isolation voltage of 500VAC, to resist on-site electromagnetic interference.

6. Wide voltage input range covering 10-30VDC (DC mode), compatible with mainstream industrial sensors and switch signals.

7. The working temperature range is -20 ℃ to 60 ℃, and it can withstand humid and dusty industrial environments with better stability than conventional modules.

8. Equipped with detachable terminal block wiring, supporting pre wiring operation, greatly improving on-site installation and maintenance efficiency.

9. Each channel is equipped with independent green LED indicator lights, synchronized module level fault indicator lights, and visualized operation and maintenance.

10. Modular and compact design, width compatible with standard DIN rail installation, saving installation space inside the control cabinet.

11. Support remote fault diagnosis, accurately identify communication abnormalities and module failures, and facilitate quick problem localization.

12. No need for additional independent power supply, obtain working power through the system backplane, simplify wiring and power supply architecture.

13. Compatible with EtherNet/IP and PROFIBUS-DP protocols, it can seamlessly integrate with mainstream controllers such as Rockwell and Siemens.

14. The shell protection level reaches IP20, the insulated body design can withstand slight water droplet splashes, and is suitable for installation conditions inside the cabinet.

15. Compliant with UL, CE, IEC 61131-2 standards, strictly following industrial safety regulations, suitable for multi industry automation scenarios.

IMDSI12  Product imag
