Product Details Introduction

Xycom XVME-976 Industrial Computing Expansion Module

Xycom XVME-976 is an industrial grade expansion carrier module with 6U VME bus standard, designed to provide flexible I/O and function expansion for VMEbus systems. It is compatible with PC/104 and PMC expansion modules, suitable for harsh industrial environments, and is the core expansion component of VME architecture control systems.

Core Features

Compatible with the VMEbus standard (IEEE 1014), it can be seamlessly integrated into the VMEbus system.

Provide 1 PC/104 expansion site, compatible with standard PC/104 modules (Ethernet, serial port, parallel port, etc.).

Provide one PMC expansion site that supports IEEE P1386 standard and can expand high-speed data acquisition, communication, FPGA and other functions.

Compatible with VME processor modules such as Xycom XVME-654/655/689/690, which can be connected directly or through an adapter board.

Onboard DC regulator provides stable 3.3V power supply for PMC sites.

The PC/104 signal (except for the data line) is buffered to ensure signal integrity.

Support custom signal routing with jumper cables to adapt to different expansion requirements.

Industrial grade design, wide temperature range, anti vibration, high reliability, to meet harsh operating conditions.

Easy installation and configuration, supporting rapid system function expansion.

Support third-party ATM, FDDI, SCSI and other expansion modules to enrich system interface capabilities.

6U standard mechanical size, compatible with standard VME chassis.

Provide inter board connectors to achieve stable electrical connection with the processor module.

Support single/dual slot configuration to adapt to different system space requirements.

Compatible with multiple real-time operating systems and suitable for industrial control scenarios.

Equipped with comprehensive power management and signal protection to enhance system stability.

XVME-976 Product imag

XVME-976  ontroller Module
