Product Details Introduction

XVME-244 is a 6U VME bus 64 channel isolated digital I/O module (32 in, 32 out) launched by Xycom, designed for high reliability discrete signal acquisition and control in industrial fields, with strong isolation, anti shake, and power on safety features.

Adopting a 6U VME bus architecture, compatible with standard VME chassis and backboards.

Integrate 32 digital inputs and 32 digital outputs, totaling 64 channels, divided into 8 groups of 8-bit ports.

300 VDC optocoupler isolation between input/output channel groups and 1000 VDC isolation from VME bus.

The input voltage range is 10-35 VDC, supporting 35 VDC reverse bias protection.

Built in input stabilization circuit to eliminate mechanical contact jitter interference.

Output supports 10-30 VDC voltage, with a maximum single channel current of 400 mA.

All outputs are equipped with transient suppression and reverse voltage protection to enhance reliability.

When powered on/reset/SYSFAIL, all outputs are disabled by default to ensure system safety.

The output status can be read back by software for closed-loop monitoring.

Supports byte/word access modes for flexible programming.

Occupy 1K bytes of VME short I/O address space, making system addressing convenient.

Industrial grade wide temperature design, operating temperature range of -40 ° C to+85 ° C.

Compliant with IEC 60068 anti vibration/shock standards, suitable for harsh environments.

Meets the safety isolation requirements of IEC 61010 and has strong electromagnetic compatibility.

Widely used in industrial automation, power monitoring, rail transit, process control and other scenarios.

XVME-244, with its high isolation, high reliability, and safe power on design, has become a classic solution for industrial grade digital I/O control in VME systems, suitable for controlling various strong interference field devices such as switches, relays, valves, etc.

XVME-244  Product imag

XVME-244 ontroller Module
