MVI56-ADMNET Server Communication Module

MVI56-ADMNET Server Communication Module

Product Details Introduction

MVI56-ADMNET is a C language programmable Ethernet server communication module developed by ProSoft for the Allen Bradley ControlLogix platform. It is used to customize protocols, interface non-standard devices with server data.

Single slot design, directly compatible with ControlLogix 1756 rack, supports local and expansion rack installation

Comes with one 10/100M adaptive Ethernet port, supporting TCP/IP, Socket communication, and custom server protocols

Equipped with 2 fully optically isolated serial ports, supporting RS-232/422/485 hardware switching

Support user C language programming and development, capable of implementing private protocols, non-standard message parsing, and customized communication logic

Provide API libraries for Ethernet, serial port, and backplane communication to simplify development and integration

Large capacity internal data buffer for flexible bidirectional data exchange with PLC controller

The parameters of serial port baud rate, data bits, parity bits, stop bits, etc. can be flexibly configured by software

Support custom heartbeat, timeout retransmission, and verification algorithms to improve communication stability

Can be used as a TCP server/client to interface with upper computers SCADA、 Database and other systems

Support parallel processing with multiple connections and communicate with multiple devices or servers simultaneously

Multiple sets of LED status indicator lights, real-time display of module operation, network, serial port, and backplane status

Industrial grade hardware design, strong anti-interference ability, suitable for harsh industrial site environments

Backboard direct power supply, no need for external power supply, simple wiring

Support configuration file download and online debugging, convenient for development and on-site maintenance

Support firmware online upgrade, continuous expansion of functions and compatibility with new devices

ending

MVI56-ADMNET is suitable for non-standard communication, private protocol docking, industrial data upload to servers, and other scenarios. It is a highly flexible customized communication module for the ControlLogix system.

MVI56-ADMNET Product imag

MVI56-ADMNET ontroller Module
