MVI69-HART communication module

MVI69-HART communication module

Product Details Introduction

MVI69-HART is a HART communication module used by ProSoft for Rockwell CompactLogix and MicroLogix 1500 LRP platforms to interface with HART smart instruments. The product has been discontinued and is mainly used for disassembly, refurbishment, and inventory spare parts.

Compatible with 1769 rack, single slot installation, directly communicating with PLC backplane.

Comes with two independent HART master station interfaces, supporting standard HART protocol communication.

It can superimpose digital signals on 4-20mA analog signals and simultaneously collect analog quantities and device parameters.

Supports point-to-point and multi-point networking, with a single link capable of connecting multiple HART devices.

Automatically polling and collecting instrument data to reduce the burden on PLC programs.

Support reading process variables such as pressure, temperature, liquid level, flow rate, and equipment diagnostic information.

Parameter configuration, calibration, status monitoring, and fault alarm can be performed on the instrument.

The module comes with a built-in data cache, ensuring stable and efficient interaction with PLC data.

Equipped with electrical isolation design and strong anti-interference ability, suitable for chemical, petrochemical, power and other sites.

Industrial grade working temperature, suitable for long-term continuous operation.

Powered by the rack 5VDC, no additional power supply is required.

Support the display of operation, communication, and fault status indicator lights.

Can connect to HART devices such as transmitters, valve positioners, and smart meters.

Used for upgrading old systems, centralized management of intelligent instruments, data collection, and remote monitoring.

Configuration is completed through dedicated software, supporting parameter settings such as channels, polling, and data mapping.

The module is mainly used for connecting Rockwell PLC systems with HART smart instruments to achieve equipment data acquisition, management, and diagnosis. It is a commonly used communication spare part for process automation.

MVI69-HART Product imag
