Product Details Introduction

00-127-754 (standard type) and 00-127-755 (extended type) are CI3 series ESC electronic safety circuit control modules specifically designed for KUKA KRC2/KRC4 control cabinets. They are responsible for managing safety circuit nodes, supplying power to teaching pendant interfaces, and monitoring safety logic. They are the core control units for the safe operation of robots.

Product features (15 items)

Model differentiation: 00-127-754 is the standard CI3 (without built-in nodes); 00-127-755 is an extended CI3 (with built-in security node).

Core function: Integrate ESC electronic safety circuit, manage safety signals such as emergency stop, safety door, brake chain, etc.

Teaching pendant adaptation: Provide X5 interface communication and X21 power supply for the 00-163-784 (C2Robot) teaching pendant.

Security monitoring: Supports multi-channel security input/output, achieving redundant monitoring and fault diagnosis of security circuits.

Status indication: Each insurance and safety node is equipped with LED indicator lights, which intuitively display the status of circuit on/off and fault.

Rich interfaces: including standardized interfaces such as safety signal terminals, teaching pendant interfaces, bus interfaces, power input, etc.

Bus compatibility: Supports safety bus communication such as SafetyBUS p and is compatible with KUKA safety control systems.

Protective design: Industrial grade PCB and terminal design, anti-interference, dust-proof, suitable for harsh workshop environments.

Stable power supply: 24V DC regulated power supply ensures stable operation of safety circuits and teaching devices.

Fault isolation: Independent insurance design, single circuit failure does not affect the normal operation of other safety circuits.

System compatibility: Perfectly compatible with KRC2 ed05 and KRC4 series robot control cabinets.

Modular structure: Standard board size, supporting DIN rail or panel installation inside the cabinet, easy to maintain.

Safety certification: Complies with industrial safety standards such as EN ISO 13849-1 and IEC 61508.

Thermal stability: wide temperature operation (0-55 ℃), no fan passive heat dissipation, reliable long-term operation.

Quick replacement: Consistent with KUKA's original specifications, supporting direct replacement of faulty modules and reducing downtime.

00127754 (00127755) CI3 Product imag

00127754 (00127755) CI3 ontroller Module
