IC697VDD100 Digital Input Module

IC697VDD100 Digital Input Module

Product Details Introduction

1、 Module positioning

IC697VDD100 is a high pass discrete input board suitable for control systems that require a large number of input points, such as power plants, petrochemicals, metallurgy, and large-scale production line control systems.

2、 Core Features

64 channel digital input

A single module provides 64 independent input points, saving rack space.

24V DC input type

Adapt to commonly used DC switch signals in industrial sites.

Optoelectronic isolation design

The input side is isolated from the internal logic circuit of the PLC to improve anti-interference ability and system stability.

Programmable filtering time

Support input debounce settings to reduce false triggering.

State of Interest (SOE) detection

Can record the time of input state changes, suitable for control scenarios with strict time requirements.

Pulse capture function

Support detection of high-frequency pulse signals.

3、 Technical parameters (typical)

Input points: 64 points

Input voltage: 24V DC

Input type: positive logic

Isolation method: Optical isolation

Installation method: Insert into the 90-70 series PLC rack

Indicator light: LED display of each channel status

4、 Application scenarios

Limit switch signal acquisition

Relay contact status detection

On site button control input

Equipment operation status feedback

High speed pulse detection occasions

IC697VDD100 Product imag

IC697VDD100 ontroller Module
