IC697VRD008 Programmable Controller Module

IC697VRD008 Programmable Controller Module

Product Details Introduction

IC697VRD008 is an Analog Output Module in the GE Fanuc 90-70 series PLC system, used to convert digital control signals inside the PLC into standard analog voltage or current signals, and drive field control devices such as valve regulators, frequency converters, analog inputs, etc.

Main functions and positioning

Type: Analog output module

Purpose: Output standard analog signals to on-site controllers or actuators

Applicable system: GE Fanuc Series 90-70 PLC

This module is usually installed in the PLC rack, together with the CPU, communication module, digital module, etc., to form the overall control system.

Main Features

Multi channel analog output

Support multiple independent analog output channels, capable of outputting current or voltage signals in different ranges.

Current/voltage output support

The module supports standard analog signal formats such as 0-20 mA, 4-20 mA, 0-10 V, etc., and the output range can be set according to the requirements of the on-site equipment.

High precision and linearity

The output has good resolution and linear characteristics, suitable for fine control applications such as regulating valve position control.

Module status diagnosis

Built in diagnostic function, which can provide feedback on output status or fault information for easy maintenance and troubleshooting.

Integration with PLC system

The output signal is directly driven by the PLC program control logic, which can realize the analog output part in the automation control strategy.

Typical Technical Parameters (Example)

Number of output channels: usually 8 analog outputs

Output type: voltage and/or current signal

Output range: commonly 0-20 mA/4-20 mA/0-10 V

Load impedance: Depending on specific output type and range requirements

Resolution: High resolution DAC output, suitable for fine control

The specific parameters may vary slightly depending on different versions and configurations. Please confirm the specific output range and load requirements when selecting.

IC697VRD008 Product imag

IC697VRD008 ontroller Module
