Product Details Introduction

IC697CHS750 is a 5-slot rear mounted I/O chassis from GE Fanuc 90-70 series, designed specifically for high-density, rear mounted distributed I/O expansion. It features compact installation, independent power supply, strong heat dissipation, and high compatibility.

1、 Core specifications and structure

Number of slots: 5 standard 90-70 module slots, compatible with the full range of IC697 modules.

Installation method: Rear Mount, panel/flange installation, saving space in front of the cabinet.

Power supply: 5V DC, maximum 20A backplane power supply; Support left independent power module, flexible expansion.

Size/Weight: 11.15 x 12.60 x 7.5 inches (H x W x D), approximately 2kg.

Shell: Open industrial chassis, NEMA/UL 1/12/3R/4 protection, indoor use.

2、 Wiring and heat dissipation design

Bottom inlet: Bottom wiring cavity, capable of accommodating 40 # 14 AWG cables, suitable for high-density I/O.

Convection heat dissipation: Open air duct design, forced/natural air cooling, stable operation from 0-60 ℃.

Backplane compatibility: Standard VME J2 backplane, optional expansion kit, compatible with redundant and remote I/O architectures.

3、 Compatibility and Scalability

Series compatibility: compatible with rack universal modules, power supplies, and communication cards such as IC697CHS790/791.

Scalability: Large distributed systems can be built through cascading Genius bus/remote I/O modules.

Application scenarios: chemical, power, metallurgical, papermaking and other applications that require post wiring and high reliability I/O.

4、 Product advantages

Space saving: rear installation+compact 5 slots, optimized control cabinet layout.

Flexible power supply: independent power supply position, supporting redundant power supply for multiple racks.

Wiring friendly: Bottom entry reduces interference inside the cabinet and is easy to maintain.

Industrial reliability: wide temperature range, strong heat dissipation, high protection, suitable for harsh working conditions.

IC697CHS750 Product imag
