P0916TA FBM242 Channel Isolation Output Module

P0916TA FBM242 Channel Isolation Output Module

Product Details Introduction

P0916TA FBM242 Channel Isolation Output Module

Belonging to the Foxboro I/A Series DCS system, it is a 16 channel external power supply and channel fully isolated discrete output module.

Each channel is independently electrically isolated, with a tolerance of 600VAC/1min between channels and to ground. It is resistant to interference and ground circulation, and is suitable for complex industrial sites.

External power supply, supporting 15-60VDC (maximum 2A per channel), 120VAC/125VDC, 240VAC multi voltage level output.

Compatible with solid-state switches and relay outputs, it can drive loads such as solenoid valves, indicator lights, intermediate relays, valve actuators, etc.

Support fail safe configuration, the output can be pre-set to a safe state (normally open/normally closed) in case of system failure, enhancing system security.

Equipped with LED status indication, it can intuitively view the operation, communication, and output status of each channel of the module, facilitating quick diagnosis.

Support redundant 2Mbps fieldbus communication to ensure stable data exchange with the controller.

Support online hot plugging, no need to disconnect power during maintenance, and do not affect the continuous operation of the system.

Industrial grade wide temperature design, operating temperature range of -40 ℃~85 ℃, meeting the strict industrial environment standards of G3.

Modular structure, DIN rail installation, combined with dedicated terminal components, easy deployment and wiring.

Seamless integration of I/A Series control system, supporting ladder logic, online diagnosis, and status monitoring.

Suitable for equipment control, alarm output, and interlocking control scenarios in industries such as petrochemicals, power, metallurgy, and water treatment.

This module, with its full isolation, multi voltage adaptation, fault safety, and high reliability characteristics, is the core output component for achieving precise and safe control of on-site equipment in industrial DCS systems. It can effectively ensure the stable operation and production safety of the control system.

P0916TA FBM242 Product imag
