853-088976-004 RF Matching Box

853-088976-004 RF Matching Box

Product Details Introduction

853-088976-004 RF matching box related instructions

853-088976-004 is an industrial grade RF matching box, with the core function of achieving precise matching between load impedance and RF source, ensuring efficient transmission of RF power, and adapting to industrial RF systems such as plasma processing and RF power amplifiers

2. Adopting a phase amplitude dual capacitor cooperative adjustment mechanism, it can dynamically compensate for impedance deviation, achieve high matching accuracy, and effectively reduce reflected power

3. Compatible with a standard 50 Ω impedance system, supports wideband RF signal matching, and covers commonly used industrial RF operating frequency bands

4. Built in high-efficiency inductor coils and precision adjustable capacitor components, with low losses and excellent matching efficiency within the rated power range

5. The working temperature range is from -10 ℃ to 55 ℃, with good environmental adaptability, and can operate stably in industrial RF equipment rooms

6. Equipped with standard SMA RF interface, high connection reliability, interface characteristics comply with RF signal transmission specifications, reducing signal loss

7. Supports switching between automatic and manual matching modes. The automatic mode can quickly respond to changes in load impedance, while the manual mode is suitable for precise debugging needs

8. Built in reflection power monitoring module, which automatically triggers protection when the reflection power exceeds the standard, avoiding damage to the RF source and load equipment

9. The shell is made of metal shielding material, which has excellent resistance to electromagnetic interference (EMI) and prevents internal RF signal leakage

10. The panel is equipped with clear status indicator lights and parameter display screens, providing real-time feedback on matching status, reflected power, and operating frequency band

11. Adopting modular structure design, easy installation and disassembly, convenient for later maintenance and component replacement

12. Before operation, it is necessary to confirm that the RF source has been turned off. It is strictly prohibited to plug or unplug the RF interface or open the equipment cover while it is live

13. When connecting the RF interface, ensure that it is aligned properly and the tightening torque meets the specifications to avoid poor contact that may cause signal reflection or interface damage

14. It is prohibited to use it under conditions exceeding the rated power and temperature to avoid the risk of internal component overheating damage or RF leakage

15. The factory has undergone full process verification including impedance matching accuracy, reflected power detection, and shielding performance testing, and meets the quality standards of industrial RF equipment
