MDX-03-3A-E113 Power Controller

MDX-03-3A-E113 Power Controller

Product Details Introduction

MDX-03-3A-E113 power controller related instructions

1. MDX-03-3A-E113 is an industrial grade power controller suitable for power rectification and power supply regulation scenarios

2. Average forward current of 300A, suitable for high current industrial power supply needs

3. The repetitive peak reverse voltage is adjustable from 400-2600V, suitable for different voltage level scenarios

4. The storage temperature range is -40 ℃ to+125 ℃, with strong environmental adaptability

5. The peak surge current reaches 12.5kA (10ms half sine wave), with excellent shock resistance

6. With excellent thermal stability, the maximum thermal resistance of the crust is 0.130 ℃/W

7. Supports multiple wiring modes including single-phase, three-phase, and six phase, adapting to different power supply systems

8. The minimum isolation voltage is 2500V (50Hz, 1 minute), and the insulation performance is reliable

9. The typical torque value for terminal connection is 12N · m, with firm installation and stable contact

10. Suitable for heat sink installation, the maximum thermal resistance from the shell to the heat sink is 0.04 ℃/W, with high heat dissipation efficiency

11. Onboard status indicator light, providing real-time feedback on operating status and fault information

12. Installation requires professional personnel to operate, strictly following torque and installation force requirements

13. Prohibit the use of overpressure and overcurrent. Before use, check the matching of voltage and current

14. Before wiring, the main power supply must be disconnected to avoid safety accidents caused by live operation

15. The factory has undergone full process testing for electrical and thermal performance, and meets industrial quality standards

MDX-03-3A-E113 Product imag

MDX-03-3A-E113 ontroller Module
