70111-6105 Spectrometer Module

70111-6105 Spectrometer Module

Product Details Introduction

70111-6105 Spectrometer Module Product Features (15 items, pure text without links)

Adopting an optimized Chenier Turner optical architecture, coupled with a high-density holographic grating, the spectral resolution can reach 0.05nm, accurately capturing fine spectral features and adapting to high-precision component analysis scenarios.

Covering a wide spectral measurement range of 200nm to 1100nm, compatible with UV and visible bands, it can meet the spectral detection needs of multiple scenarios such as material analysis, water quality monitoring, and industrial quality inspection.

Equipped with a high-sensitivity cooling CMOS detector, the dark current is as low as nA level, and the signal-to-noise ratio (SNR) is ≥ 80dB. It can accurately detect trace components and weak light signals, reducing the measurement limit.

Built in optical system constant temperature module, with a temperature control accuracy of ± 0.1 ℃, effectively suppressing wavelength drift, ensuring long-term measurement data consistency, and adapting to industrial online continuous monitoring needs.

Supports high-speed spectral acquisition, with a fastest sampling rate of up to 1000 spectra per second. Coupled with real-time data processing algorithms, it can meet the needs of dynamic process monitoring and rapid response analysis scenarios.

Integrated multi interface communication system, including Gigabit Ethernet, USB 3.0, and RS485, supporting Modbus and TCP/IP protocols, with data transmission delay ≤ 1ms, suitable for remote control and data upload requirements.

Built in spectral data preprocessing function, supporting algorithms such as baseline correction, smooth denoising, peak position recognition, etc., can directly output analysis results, simplifying the data processing flow of the upper computer.

Equipped with fiber optic interfaces, supporting multi-channel fiber switching, capable of simultaneously connecting multiple measurement points, achieving parallel detection at multiple workstations, and improving detection efficiency.

Equipped with hardware level data encryption and permission management functions, it prevents spectral data tampering and unauthorized access, ensuring the security and traceability of analytical data.

Support automatic wavelength calibration and drift compensation, built-in standard spectral library, customizable calibration cycle, no need for frequent manual calibration, reducing operation and maintenance costs.

Working temperature range -10 ℃~+50 ℃, relative humidity 5% -95%, no condensation, protection level IP40, anti vibration, anti electromagnetic interference, suitable for complex industrial site environments.

Adopting a fanless low-power design with a rated power consumption of ≤ 15W, it is suitable for portable measurement scenarios with embedded system integration and no external power supply, energy-saving and environmentally friendly.

Support offline data storage, built-in 8GB storage space, can cache ≥ 1 million spectral data, data will not be lost after power failure, easy to trace and replay in the future.

70111-6105  Product imag
