IMDS014 Analog Output Module

IMDS014 Analog Output Module

Product Details Introduction

IMDS014 Digital Output Module Product Features (15)

1. Equipped with an open collector output design and 16 independent digital output channels, it meets the simultaneous control requirements of multiple devices.

2. Supports dual specification load switching of 24VDC 250mA and 48VDC 125mA, adapting to different power requirements of on-site devices.

3. Adopting optoelectronic coupling isolation technology, the isolation voltage between channels reaches 1.5kV, effectively blocking electromagnetic interference in the ground loop.

4. The maximum load current of a single channel can reach 370mA, with a rated contact current of 4A, and strong load capacity suitable for industrial scenarios.

5. Fast response speed, contact action response time<10ms, can meet high-speed switching control requirements.

6. The wide temperature working range covers -40 ℃ to 70 ℃, and can withstand harsh industrial environment temperature differences.

7. The protection level reaches IP65 (NEMA 4X), with dust-proof and moisture-proof performance, suitable for harsh on-site conditions.

8. Supports both DIN rail and panel installation methods, standardized size design, easy installation and space saving.

9. Built in status indicator LED, divided into module operation status (red and green dual color) and channel output status (16 independent channels), visual operation and maintenance.

10. Compatible with ABB Symphony DCS system and seamlessly integrated with mainstream industrial automation control platforms.

11. Adopting high-quality components and fanless design, the structure is sturdy, with high long-term reliability and low failure rate.

12. Supports hot swapping function, allowing for module replacement without system shutdown, ensuring continuous operation of the production line.

13. Equipped with short-circuit protection and overload detection functions, automatically avoiding damage to modules and equipment caused by abnormal loads.

14. Support industrial bus protocols such as Profibus and EtherCAT to achieve remote control and data exchange.

15. Single printed circuit board design, occupying only one installation slot in the system, with high space utilization and easy system expansion.

IMDS014  Product imag
