1336-L6E/L9E interface board

1336-L6E/L9E interface board

Product Details Introduction

1336-L6E/L9E is a dedicated control interface board for Allen Bradley 1336 series frequency converters, integrating encoder feedback and 115V AC power supply. It is designed for high-precision speed regulation and positioning scenarios, with the following core features:

Compatible with the full range of 1336 IMPACT, FORCE, Plus II and other frequency converters

Integrated encoder feedback interface, supporting high-precision speed/position closed-loop control

Adopting 115V AC independent power supply, compatible with global industrial power grid standards

Provide 9 digital inputs to meet the needs of multiple signal access

Built in signal isolation circuit to enhance anti-interference and system security

Industrial grade PCB design, suitable for working environments with a wide temperature range of 0-50 ℃

Support direct replacement of interface boards of the same series, easy to maintain

Compatible with NEMA and European standards, globally applicable

Compact size (17.8 × 2.5 × 7.6cm), small installation space occupation

Built in fault diagnosis circuit, easy to quickly locate problems

Support parameter storage, configuration will not be lost after power failure

Adapt to vector control and VF control modes, with flexible application

Compliant with international safety certifications such as UL, CE, CSA, etc

Using high-quality components, stable and durable operation

Suitable for high-precision transmission scenarios such as machine tools, printing, textiles, etc

In summary, the 1336-L6E/L9E interface board, with its core advantages of high-precision feedback, strong compatibility, and high reliability, is a key component for achieving precise control of the 1336 series frequency converter.

1336-L6E/L9E Product imag

1336-L6E/L9E ontroller Module
