Product Details Introduction

Introduction to 1746-OX8 Isolation Relay Output Module

1746-OX8 is a Rockwell SLC 500 series 8-channel isolation relay output module designed specifically for strong electrical loads and high safety isolation requirements. The following is a detailed introduction:

Belonging to SLC 500 series 8-channel relay output module

Complete electrical isolation between channels, strong anti-interference ability

Supports both AC and DC loads, with a wide range of applications

Each output is equipped with an independent LED status indicator light

Using mechanical relay contacts, with low conductivity and strong load-bearing capacity

Support normally open contact output mode

Equipped with surge suppression circuit to extend the service life of relays

Detachable terminal block design, convenient wiring and maintenance

Occupy a single slot position in the SLC 500 rack

Powered by 5V DC from the backplane, no additional auxiliary power supply required

The working temperature range is suitable for various industrial site environments

High voltage isolation between output and PLC backplane to enhance system safety

Can directly drive high-power equipment such as contactors, alarms, valves, etc

Suitable for switch control scenarios that require electrical isolation

This model has been discontinued, and the market mainly consists of second-hand and refurbished spare parts

In summary, 1746-OX8 is a highly reliable isolation relay output module in the SLC 500 system. With its channel isolation and strong load capacity, it is widely used in industrial control applications that require high safety and stability.

1746-OX8 Product imag

1746-OX8 ontroller Module
