Product Details Introduction

1747-L511 processor unit introduction

1747-L511 is an entry-level CPU module for Rockwell Allen Bradley SLC 500 series SLC 5/01, providing basic logic control and network communication capabilities for small single machine control systems.

Processor level: SLC 5/01, SLC 500 series basic entry-level CPU

User memory: * * 1K words (1024 words) * * Capacitive backup RAM, can save programs for a short time when powered off

Program execution: Typical scanning speed of 8ms/thousand instructions, bit execution of approximately 0.37 μ s

I/O capability: Supports up to 256 digital I/O points and 32 analog I/O points; Up to 1 local expansion rack

Communication interface: Built in DH-485 port (9-pin D-Sub), supporting point-to-point network communication

Memory Expansion: Compatible with 1747-M1 (1K) and 1747-M2 (4K) EEPROM modules

Power supply and power consumption: Backboard 5V DC power supply, current 90mA, power consumption about 1.75W

Installation: Must be installed in slot 0 of SLC 500 rack, occupying a single slot

Status indication: LED indicator lights for module operation, fault, and communication status

Programming software: Use RSLogix 500 for ladder diagram programming and configuration

Environment: Working temperature 0-60 ° C, in compliance with industrial site usage requirements

Application: Small single machine control, material handling, simple process control, HVAC system

1747-L511 Product imag

1747-L511 ontroller Module
