PROTECH SYSTEMS PBI-6SA Printed Circuit Board (Vibration Protection Module)

PBI-6SA is a 6-channel vibration monitoring and protection PCB module designed by PROTECH SYSTEMS specifically for rotating machinery. Its core is used for vibration over limit warning and shutdown protection of key equipment such as steam turbines, compressors, pumps, and fans. It is an important safety monitoring unit in industrial DCS/PLC systems.

1、 Core positioning and functions

6-channel vibration input: can simultaneously monitor the vibration signals of 6 measuring points, covering multiple bearing/multi unit monitoring scenarios.

Real time monitoring+multi-level protection: Built in vibration amplitude/intensity calculation, supports alarm and danger two-level relay output, automatically triggers shutdown or interlocking when exceeding the limit.

Industrial grade protection: The front panel is NEMA 4X/IP66, dustproof, waterproof, and corrosion-resistant, suitable for harsh environments such as chemical plants, power plants, and metallurgy.

Wide voltage power supply: compatible with multiple specifications of DC/AC inputs, suitable for global industrial power grid environments.

Dual installation method: Supports panel embedded installation and DIN rail installation, flexibly integrated into the control cabinet.

Status visualization: onboard LED indicator lights, real-time display of channel status, alarm/danger, power and communication status.

Signal conditioning and isolation: Built in signal amplification, filtering, electrical isolation, resistant to on-site electromagnetic interference, ensuring measurement accuracy.

Relay output: Provides multiple sets of dry contact outputs, which can be directly connected to PLC/DCS or drive sound and light alarm and shutdown circuits.

Wide temperature stable operation: Operating temperature range of -40 ℃ to+85 ℃, meeting long-term reliable operation under extreme working conditions.

Low power design: Typical power consumption is about 2W, suitable for densely installed control cabinet cooling environments.

Compact size: Small in size (approximately 22.5 × 16.5 × 10mm), saving space inside the cabinet.

Standardized interface: terminal wiring, wiring specifications, easy to install and maintain on site.

Compatible with mainstream systems: It can seamlessly integrate with DCS/PLC platforms such as Foxboro, Triconex, ABB, etc. as an independent protection unit or system expansion module.

Long life components: Industrial grade component selection, supporting 7 × 24-hour continuous operation and reducing maintenance frequency.

Application scenarios: Widely used for vibration safety protection of rotating machinery such as power plant steam turbines, petrochemical compressors, metallurgical fans, and water plant pump sets.
