XYCOM 5017-T Operation Interface Panel

XYCOM 5017-T is a 17 inch industrial grade high-resolution touch control panel that utilizes Smart Panel technology. It integrates high protection, wide temperature range, multiple interfaces, and flexible installation, providing stable human-machine interaction for harsh industrial scenarios such as DCS/PLC systems, production line monitoring, and process control.

Core Features

17 inch TFT LCD, SXGA resolution 1280 × 102416 million colors, clear and delicate display.

8-wire analog resistive touch screen, supporting precise touch control, suitable for glove operation in industrial sites.

The front panel is NEMA 4/4X/12, IP65 protected, fully sealed, dustproof and splash proof, and resistant to oil stains and water vapor.

Supports VGA, analog video, DVI digital video input, compatible with multiple signal sources.

Standard RS-232 touch interface, optional USB touch interface, strong driver compatibility.

Wide voltage power supply: 100-240VAC (1A, 50/60Hz) or 18-30VDC (maximum 2.5A).

Wide temperature operation (0 ℃~50 ℃), storage temperature -20 ℃~60 ℃, anti vibration and anti electromagnetic interference.

The shallow installation depth is only 2.85 inches (72.4mm), suitable for compact control cabinets.

Supports panel embedded installation and 100mm VESA cantilever installation, with flexible installation.

The front panel integrates Menu, up and down arrows, and adjustment buttons for easy local operation.

Can be paired with Xycom 1546 Node or 1330 Client PC to form an integrated workstation.

Built in image scaling engine, sharp and distortion free full screen display.

All metal structure, passive heat dissipation, reduces the risk of fan failure.

Compliant with industrial certifications such as UL 508, UL 1604, cUL, CSA, CE, FCC, etc.

5017-T Product imag

5017-T ontroller Module
