SEW MDV60A0015-5A3-4-00 servo drive

SEW MDV60A0015-5A3-4-00 servo drive

Product Details Introduction

SEW MDV60A0015-5A3-4-00 is a 1.5kW high-performance servo drive from MOVIDRIVE MD-60A series, featuring vector closed-loop control, high dynamic response, and industrial bus compatibility, suitable for asynchronous/synchronous servo motors.

15 core characteristics

Rated power: 1.5kW, three-phase 380-500V input, 50/60Hz universal.

Rated current: Input 3.6A (400V), output 4.0A (400V), suitable for low-power servo motors.

Control mode: Supports VFC (Voltage Flux Control), CFC (Current Flux Control), SERVO servo mode, with or without encoder.

Closed loop accuracy: Supports incremental encoders and feedback from rotary transformers to achieve position/velocity/torque triple loop control.

Overload capacity: 150% rated current can last for 60 seconds, 200% short-term overload, suitable for impact loads.

Output frequency: adjustable from 0.1-400Hz, meeting the requirements of high-speed and precise positioning.

Built in IPOSplus: integrates positioning and sequential control functions, supports multi-stage speed, point-to-point positioning, and does not require an additional PLC.

Safety function: Built in STO (Safe Torque Off), meets SIL2 safety level, supports safe shutdown.

Communication interface: Standard RS-485, supports PROFIBUS, PROFINET, DeviceNet, Modbus and other buses (requires expansion card).

I/O configuration: 6 isolated digital inputs, 3 digital outputs (including programmable relays), 2 analog inputs/outputs.

Protection function: Full protection against overvoltage, undervoltage, overcurrent, overheating, motor stalling, ground fault, and encoder abnormality.

Heat dissipation design: forced air cooling, compact structure, suitable for continuous full load operation.

EMC performance: Built in C3 level EMC filter, compliant with EN 61800-3 standard, strong anti-interference.

Parameter storage: 128kB FRAM, keep parameters in case of power failure, no need for battery backup.

Application scenarios: high-precision transmission scenarios such as packaging machinery, printing equipment, robots, conveyor lines, precision positioning platforms, etc.

ending

MDV60A0015-5A3-4-00 has become the mainstream choice for low-power high-precision servo drives due to its high dynamic performance, high reliability, and strong compatibility.

MDV60A0015-5A3-4-00 Product imag
