MVI56-DNPSNET Ethernet Server Communication Module

MVI56-DNPSNET Ethernet Server Communication Module

Product Details Introduction

MVI56-DNPSNET Ethernet Server Communication Module Product Features

MVI56-DNPSNET is a DNP3 Ethernet server communication module developed by ProSoft for the Rockwell ControlLogix platform. It is mainly used for SCADA system communication in industries such as power, energy, and water. The following are the core product features:

Compatible with the ControlLogix platform, single slot backplane direct insertion, easy installation and deployment

10/100Mbps adaptive Ethernet interface, supporting DNP3 Ethernet communication

Compatible with DNP3.0 protocol standard, meeting the requirements for industrial SCADA master station access

Support active uploading of data changes, reduce network load, and improve communication real-time performance

Large capacity data and event caching, automatically replenishing data after communication interruption

Supports multiple data types such as binary, analog, counter, event, etc

Asynchronous data exchange with PLC controller, without occupying the main scanning cycle of the system

Support timestamp function to meet the data traceability needs of the power and energy industries

Provide standard PLC function blocks for easy integration and calling in ladder diagrams

Independent configuration port, supporting parameter configuration, online debugging, and program download

LED status indicator light for quick on-site diagnosis of module and communication status

Network side electrical isolation enhances anti-interference capability and improves operational stability

Support simultaneous connection of multiple clients to meet the monitoring scenarios of multiple main stations

Industrial grade wide temperature, anti vibration, and anti impact design, suitable for harsh on-site environments

Suitable for automation systems such as power automation, oil and gas monitoring, water dispatch, etc

This module has strong protocol compatibility, stable and reliable communication, and is a high-quality solution for ControlLogix system to connect to DNP3 Ethernet network, achieve remote monitoring and data exchange.

MVI56-DNPSNET Product imag

MVI56-DNPSNET ontroller Module
