Product Details Introduction

MVI56-103M Communication Module

MVI56-103M is an IEC 60870-5-103 power protocol communication module used by ProSoft for the Rockwell ControlLogix platform. It is mainly used for data communication of power system relay protection devices. The product has been discontinued and is mainly available in the market as disassembled, refurbished, and original stock spare parts.

Compatible with 1756 rack, single slot installation, directly communicating with PLC backplane.

Equipped with 2 independent isolated serial ports, supporting RS-232, RS-485, and RS-422.

Working in IEC 103 master station mode, actively collecting data from protective devices.

Specially designed for the power industry, compatible with various relay protection and measurement and control equipment.

Support remote signaling, telemetry, remote control, SOE event, and fault recording data transmission.

Support event grading upload to meet the real-time requirements of the power system.

The module comes with a built-in data cache, which enables efficient and stable interaction with PLC data.

Equipped with communication diagnosis, error statistics, and automatic reconnection for disconnections.

Strong electrical isolation, good anti-interference ability, suitable for industrial environments such as substations.

The working temperature is 0-60 ℃, and it can operate continuously for a long time.

Powered by the rack 5VDC, no additional power supply is required.

Support status indicator lights for easy viewing of operational and communication status.

Multiple protection devices, measurement and control devices, RTUs and other power equipment can be connected.

Mostly used for substation automation, power plant electrical monitoring, and power SCADA system integration.

The configuration is completed through dedicated software, and the parameter settings are flexible and reliable.

This module is a dedicated communication spare for ControlLogix PLC to interface with IEC 103 equipment in the power system, mainly used for the renovation of old power systems and equipment networking.

MVI56-103M Product imag

MVI56-103M ontroller Module
