Product Details Introduction

00-109-040 is a KVGA 2.0 video interface board specifically designed for KUKA KRC2/KRC2 ED05 control cabinet. Its core function is to connect an industrial computer with a teaching pendant (KCP) and an external display, enabling video signal output and interactive control.

Product positioning: KVGA 2.0 video interface board, spare part number 00-109-040, compatible with KRC2 and KRC2 ED05 control cabinets, replacing the early KVGA 1.0 version.

Core function: Process graphics data from industrial control computers, output video signals to teaching devices and external VGA displays, and achieve system interface visualization.

Interface configuration: Dual KCP teaching pendant interface+1 standard VGA interface, supporting parallel display of teaching pendant and external monitor.

Signal standard: Compatible with VGA video standard, with a maximum resolution of 1024 × 768, a refresh rate of 60Hz, and clear and stable images.

Communication connection: Directly connected to the MFC3 processor module (00-109-026) through an internal bus, with real-time signal transmission without delay.

Power supply specification: 24V DC power supply, voltage range 18-30V DC, powered by auxiliary power supply of control cabinet, no additional power supply required.

Hardware design: Industrial grade PCB, metal shielding shell, anti electromagnetic interference, suitable for complex electromagnetic environments in workshops.

Status indication: Onboard LED indicator lights display real-time power supply, video output, and communication status for quick diagnosis.

Plug and play: original design, interface consistent with KVGA 2.0 standard, no need for modification for replacement, easy maintenance.

Heat dissipation design: fanless passive heat dissipation, working temperature -10 ℃~+55 ℃, supporting 24-hour continuous operation.

Protection function: Built in overvoltage, overcurrent, and short-circuit protection, hardware watchdog, automatic fault reset.

EMC compliance: Passed EN 61000-6-2/6-4 electromagnetic compatibility certification, with strong anti-interference ability.

Software compatibility: Supports KSS 5. x/6. x systems, compatible with teaching pendant operation, program editing, and system monitoring.

Application scenarios: Used for robot programming and debugging, production line monitoring, fault diagnosis, and adaptation to medium load robots such as KR 16 and KR 30.

Compliance certification: Passed CE and T Ü V certifications, in compliance with EU industrial equipment safety regulations.

Compatibility: Compatible with KCP2 and KCP2.0 teaching devices, supporting external standard VGA industrial displays.

00-109-040 Product imag
