00-108-473 Input/Output Board Unit

00-108-473 Input/Output Board Unit

Product Details Introduction

00-108-473 is a digital input/output (I/O) board unit dedicated to the KUKA KRC2/KRC2 ED05 robot control cabinet, used for signal interaction between the robot and external sensors and actuators.

Adaptation System: Designed specifically for KUKA KRC2 and KRC2 ED05 control cabinets, compatible with control modules such as MFC3 and CI3.

Channel configuration: Standard configuration includes 16 digital inputs (DI) and 16 digital outputs (DO), totaling 32 basic I/O channels.

Input type: 24V DC NPN/PNP compatible, supports dry contact and active sensor signal access.

Output type: 24V DC transistor output, maximum single channel driving current of 0.5A, suitable for loads such as solenoid valves and relays.

Signal isolation: The input/output channels are optically isolated, with strong anti-interference ability, protecting the controller from external surge impact.

Status indication: Each DI/DO is equipped with an independent LED indicator light, which displays the signal on/off in real time for quick diagnosis.

Power supply method: Powered by a 24V DC auxiliary power supply from the control cabinet, no additional independent power supply is required, simplifying system wiring.

Address configuration: Supports hardware address dialing or software configuration, and can be cascaded and expanded with other I/O boards.

Communication interface: Communicate with the controller CPU through the DSE-IBS internal bus, with high real-time signal transmission.

Wiring method: Standard terminal block wiring, clear channel numbering, supports fast on-site wiring and maintenance.

Industrial design: metal shell reinforcement, earthquake resistance, dust resistance, suitable for harsh workshop environments.

Wide temperature operation: The working temperature ranges from -10 ℃ to+55 ℃, meeting the environmental requirements of industrial sites.

Protection function: Built in overcurrent and short-circuit protection to prevent external faults from damaging the module.

Plug and play: original design, interface definition consistent with the original factory, easy replacement and maintenance.

Application scenario: Used for automated production lines such as handling, assembly, welding, etc., to achieve signal interaction between robots and peripheral devices.

Compliance certification: Passed industrial safety certifications such as CE and T Ü V, in compliance with EU standards.

00-108-473 Product imag
