PH603-2820 00-108-032 Robot Power Module

PH603-2820 00-108-032 Robot Power Module

Product Details Introduction

PH603-2820 (original spare part number 00-108-032) is a 27.3V/20A servo power module customized by German MGV for KUKA KRC2 robot control cabinet. Its power level is suitable for medium and low load axis groups and system power supply, providing stable and reliable DC bus power for industrial robots.

Core electrical specifications

Rated output: 27.3VDC, 20A, power of approximately 546W, suitable for KRC2 medium power servo drive requirements.

Input voltage: three-phase 380-480VAC, 50/60Hz, compatible with industrial standard power grid.

Output adjustment: adjustable in a wide range of 23.5-28.5V to meet the fine-tuning needs of different working conditions.

Conversion efficiency: ≥ 94%, low loss design, suitable for long-term continuous operation.

Voltage stabilization accuracy: Output ripple ≤ 50mV, fast dynamic response, suitable for frequent start stop of robots.

Structure and installation characteristics

Original factory adaptation: specially designed for KUKA KRC2 control cabinet, with 00-108-032 as the unique original spare part number.

Compact size: Industrial grade standard packaging, accurately matching the installation position inside the cabinet, without the need for additional modifications.

Metal shell: Strong and earthquake resistant, resistant to electromagnetic interference, suitable for workshop environments with high dust and vibration.

Plug and play: The standard interface is directly connected to the KRC2 system, and the pin definition is consistent with the original factory, making maintenance convenient.

Heat dissipation optimization: Efficient heat dissipation design, supporting natural air cooling of cabinets, stable operation in high temperature environments.

Reliability and protection functions

Multiple protections: Built in overvoltage, overcurrent, short circuit, overtemperature, and input undervoltage protection, automatically cutting off in case of faults.

High anti-interference: EMC complies with EN 61800-3 C3 standard, suppressing electromagnetic interference between the power grid and servo.

Wide temperature range: -10 ℃ to+55 ℃ industrial grade temperature range, suitable for harsh workshop environments.

Long life design: high-quality components, 100% aging testing, MTBF≥50, 000 hours.

Anti reverse connection protection: The output end is designed to prevent reverse connection, avoiding module damage caused by installation errors.

Application and Authentication

Exclusive application: KUKA KRC2 series robot controller, covering automated production lines such as handling, assembly, and welding.

Compliance certification: Passed T Ü V, CE, ISO 9001 certification, in compliance with EU industrial safety standards.

PH603-2820 00-108-032 Product imag
