KCP2-SP/00-122-430 teaching pendant

KCP2-SP/00-122-430 is a teaching handheld teaching pendant designed by KUKA specifically for the KRC2 ed05 control system. The core difference from the 429 model is that it comes standard with a 20 meter dedicated connection cable, which is suitable for large space teaching and training as well as long-distance robot debugging scenarios.

Core features of the product

System exclusive adaptation: Only compatible with KUKA KRC2 ed05 robot control cabinet, stable communication, plug and play.

Teaching optimization design: Simplify operational logic, adapt to novice programming teaching, and reduce the threshold for industrial robot training.

Complete safety protection: Integrated with a red mushroom head emergency stop button and a three-stage enable switch, in compliance with safety standards such as EN418.

Precise operation control: equipped with a six dimensional joystick, supporting precise point-to-point movement of the robot's linear movement and axis rotation.

Clear information display: Industrial grade LCD display screen, presenting program, coordinate, diagnostic, and status data clearly.

Convenient input layout: combination of numeric keypad and function keys, including programmable custom keys, to improve operational efficiency.

Long distance cable configuration: Comes standard with a 20 meter wear-resistant and anti torsion dedicated cable, meeting the needs of large-scale teaching and remote operation.

Lightweight and portable design: The body is lightweight, comfortable to hold, and suitable for long-term teaching demonstrations and practical training.

Industrial environment tolerance: The shell is dustproof and oil proof, suitable for complex environments in workshops and training centers.

Comprehensive functional coverage: supports program writing, trajectory teaching, I/O configuration, parameter setting, and system diagnosis.

Multi language support: Built in display of multiple languages such as Chinese, suitable for teaching and usage needs in different regions.

Direct power supply mode: Powered by KRC2 control cabinet through connecting cables, no additional power supply required, easy to install.

Powerful diagnostic function: Real time display of robot fault codes and operational data, facilitating teaching and troubleshooting.

Convenient program management: supports program creation, editing, saving, and import/export, meeting the needs of teaching and practical training.

Complete compliance certification: Passed CE certification and meets the requirements of low voltage, EMC, and mechanical safety related directives.

This teaching pendant is the core equipment for large space teaching and training in the KUKA KRC2 system. The long cable design greatly enhances operational flexibility, while also considering safety and convenience, providing an efficient human-machine interaction tool for industrial robot talent cultivation.

KCP2-SP/00-122-430 Product imag
