VE3051C0 power controller

VE3051C0 power controller

Product Details Introduction

VE3051C0 (spare part number KJ4001X1-BA3/12P3378X012) is a 2-plot wide power controller carrier specifically designed for the Emerson DeltaV M series. It integrates power distribution and controller carrying functions, providing stable power supply and local bus connection for the system, and is suitable for hazardous areas and harsh industrial environments.

Product Features

2-slot wide structure: Standard M-series wide carrier design, capable of carrying 1 controller module and integrating power distribution.

Centralized power management: Supports 30VDC/8A input, integrates on-site power supply and local bus power transmission, with a maximum output of 15A.

LocalBus bus compatibility: Fully compatible with the DeltaV local bus protocol, ensuring high-speed and stable communication between the controller and I/O modules.

Hazardous Area Compliance: With Class I Div 2 and Zone 2 explosion-proof certifications, it can be used in hazardous industrial sites.

Wide temperature operating range: working temperature from -40 ℃ to+70 ℃, suitable for extreme high and low temperature industrial sites.

Strong anti vibration and anti impact: can withstand 10g half sine wave 11ms impact; 5-16Hz 1mm peak to peak value, 16-150Hz 0.5g vibration.

High humidity adaptation: Supports 5% -95% non condensing relative humidity, with an IP20 protection level.

G3 anti-corrosion grade: Complies with ISA-S7.1.04 G3 anti-corrosion standard, resistant to dust and oil erosion.

Bus length limit: When combined with the rack, the total length of LocalBus is ≤ 6.5 meters to ensure signal integrity.

Power off operation requirements: It is strictly prohibited to plug or unplug with power on, and installation/disassembly must be carried out after the system is powered off.

Standard DIN rail installation: compatible with standard T-shaped DIN rails and compatible with various industrial control cabinets.

No user repairable parts: The overall sealed structure requires no maintenance or calibration, reducing the number of failure points.

Compact size design: approximately 11.9cm x 5.1cm x 10.8cm, weighing approximately 0.2kg, optimizing cabinet space.

Multiple safety protections: Built in overvoltage, overcurrent, and overheating protection to ensure the safety of system power supply.

Original factory quality assurance: Produced in the United States with complete serial numbers, providing standard warranty services.

ending

VE3051C0 is the core component of the DeltaV system for centralized power management and controller support. With stable power supply capability, strict safety certification, and strong environmental adaptability, it is widely used in DCS systems for process industries such as petrochemical, power, and coal chemical industries; Installation must strictly follow the DeltaV hardware manual and hazardous area regulations to ensure long-term safe and stable operation of the system.

VE3051C0 Product imag
