Product Details Introduction

KJ1501X1-BB1 is a DC power module in Emerson DeltaV distributed control system, belonging to the system level DC/DC power supply unit, mainly providing stable internal DC power for controllers and I/O modules.

1、 Product positioning

This module is used for internal power supply in the DeltaV system cabinet and is usually installed as a basic power supply component in the power supply motherboard or dedicated power slot.

It converts external DC input into stable DC output required by the system, ensuring the continuous operation of the control system.

2、 Main features

DC input design

Suitable for DC power supply environment, commonly used as 24V DC input system.

Stable DC output

The output is the internal standard voltage of the system (usually 12V DC), used to drive the controller and related modules.

High reliability structure

Equipped with industrial grade anti-interference capability, suitable for continuous operation environment.

Support redundant configuration

It can form a dual power redundancy structure with modules of the same model to improve system reliability.

Compact modular design

Easy to install, simple to maintain, and convenient for system expansion.

3、 Typical technical parameters

Input type: DC input

Common input voltage: 24V DC

Output voltage: 12V DC

Output current: configured according to system load

Installation Method: DeltaV System Power Base Plate Installation

Redundancy support: Supports dual power supply structure

KJ1501X1-BB1 Product imag
