KJ1501X1-BA2 system power module

KJ1501X1-BA2 system power module

Product Details Introduction

KJ1501X1-BA2 is a system level power module in Emerson DeltaV distributed control system (DCS), mainly used to provide stable DC power supply for controllers, I/O modules, and related system components. It is the core power supply unit for the operation of the entire system.

1、 Product positioning

This module belongs to the basic power unit of the DeltaV control system and is usually installed in the system power supply motherboard or dedicated power slot. It converts the input AC or DC power on site into the low-voltage DC power required by the system internally.

In critical control systems, power modules often adopt redundant configurations to improve overall system reliability.

2、 Main features

Wide range input

Supports AC or DC input power supply to adapt to different on-site power supply environments.

Stable DC output

Provide the required 12V DC output voltage for the system to ensure stable operation of the control module.

Support redundant operation

It can be connected in parallel with the same model of power supply to form a dual power supply structure, achieving automatic switching.

Industrial-grade design

Strong anti-interference ability, suitable for continuous operation in industrial environments.

Hot swappable capability

The module can be replaced when the system is powered on (subject to meeting the system configuration conditions).

3、 Typical technical parameters

Input voltage: Wide range AC or DC input

Output voltage: 12V DC

Output current: Depending on the system load

Installation method: DeltaV system power slot installation

Redundancy support: Supports

4、 Application scenarios

Petrochemical automation system

Power plant DCS system

Pharmaceutical process control

Water treatment and environmental protection engineering

Key control system for continuous operation

KJ1501X1-BA2 Product imag
