Product Details Introduction

Introduction to GE Fanuc IC697PWR720 power adapter module

IC697PWR720 belongs to the power adaptation module (PSA) of the 90-70 series PLC system. It is not a programmable controller CPU, but a dedicated module used to introduce external DC power into the PLC rack and supply power to various functional modules through the backplane.

1、 Module positioning

Type: Power Supply Adapter

Installation position: Power slot on the leftmost side of the rack

Function: Connect external power supply and distribute voltage to the backplane

Not equipped with program operation or control functions

2、 Main electrical parameters

Input method: DC voltage provided by external industrial power supply

Output voltage (distributed through backplane):

+5VDC

+12VDC

-12VDC

+5V output current capability of approximately 18A

+12V output current is about 2A

-12V output current is about 1A

3、 Functional Features

Support single rack or expansion rack power supply

Equipped with a power status indicator light

Support power OK signal monitoring

Industrial grade design, suitable for continuous operation environment

4、 Application Fields

Power plant control system

Petrochemical automation

Metallurgical control system

Large scale manufacturing production line

distributed control system

IC697PWR720 Product imag
