P0926EQ FBM202 Logic Controller

P0926EQ FBM202 Logic Controller

Product Details Introduction

P0926EQ FBM202 Thermocouple/Millivolt Input Module (Non Logic Controller) Product Features (15)

Specially designed for Foxboro I/A Series DCS, 8-channel isolated thermocouple/millivolt signal acquisition module.

Supports a full range of standard thermocouples such as J/K/T/E/S/R/B/N, covering a temperature range of * * -400 ℃~1700 ℃ * *.

Compatible with 0~100mV millivolt signal input and compatible with various analog sensors.

Built in 1 independent RTD cold end compensation channel, automatically correcting terminal temperature errors, with high temperature measurement accuracy.

Using 16 bit ∑ - Δ AD conversion, the accuracy reaches * * ± 0.03% of full scale * *, and the noise is less than 1 μ Vrms.

2500Vrms electrical isolation between channels, resistant to strong electromagnetic interference, ensuring signal purity.

Equipped with thermocouple wire breakage detection (upper range), it can quickly alarm in case of abnormalities, making it easy to troubleshoot.

Supports overvoltage, reverse connection, and surge protection, protecting modules and on-site temperature measurement devices.

Industrial grade wide temperature range: * * 0 ℃~+60 ℃ for operation, -40 ℃~+85 ℃ for storage, suitable for harsh working conditions.

Standard DIN rail/slot installation, compact structure, simple wiring.

Support tool free hot plugging, online maintenance does not affect the continuous operation of the system.

Built in signal filtering and integration to suppress on-site interference, ensuring stable data without drift.

The red and green LED status lights on the front panel display the real-time operation status of channels and modules.

Compatible with Foxboro fieldbus protocol, seamlessly integrated with FCM communication module, and easy system integration.

Compliant with UL, CSA, CE industrial standards, flame retardant and environmentally friendly, meeting process industry safety regulations.

concluding summary

P0926EQ FBM202 is a high-precision and highly isolated thermocouple/millivolt signal acquisition core module in Foxboro DCS system. It has the core advantages of automatic cold end compensation, multiple protection, and strong anti-interference, and is widely used in industrial scenarios such as chemical, power, metallurgy, and petrochemical industries that require precise temperature monitoring.

P0926EQ FBM202 Product imag

P0926EQ FBM202 ontroller Module
