P0972ZA FCM100E fieldbus communication module

P0972ZA FCM100E fieldbus communication module

Product Details Introduction

P0972ZA FCM100E fieldbus communication module product features (15 items)

Specially designed for Foxboro I/A Series DCS, achieving bidirectional high-speed conversion between 100Mbps Ethernet and fieldbus.

Compatible with dual rate fieldbus: 2Mbps (200 series FBM), 268Kbps (100 series FBM), compatible with a full range of I/O modules.

Support module level redundancy, dual module activation simultaneously, seamless switching in case of single module failure, and uninterrupted communication.

Maximum mounting capacity: 32 200 series FBMs or 64 100 series FBMs, with strong system scalability.

Adopting fiber optic communication, it has strong resistance to electromagnetic interference, supports long-distance transmission, and is suitable for strong interference industrial environments.

Support tool free hot plugging, online maintenance and replacement, without affecting system operation.

Industrial grade wide temperature operation: 0 ℃~+70 ℃, suitable for harsh working conditions such as chemical, power, metallurgy, etc.

Power supply range of 21-42VDC, low power consumption (maximum 5W), suitable for industrial site power environment.

Standard DIN rail installation, compact structure, saves cabinet space, and neat wiring.

Built in status LED indicator light, real-time display of communication and module operation status, facilitating quick diagnosis.

Support dual network redundancy and fiber ring network self-healing to ensure high availability of data transmission.

Channel electrical isolation design enhances the system's anti-interference and safe operation capabilities.

Compliant with CE and IEC industrial standards, flame retardant and environmentally friendly materials, meeting factory safety regulations.

Compatible with Foxboro standard backplate and base, with strong versatility and convenient system integration.

Long lifespan, anti vibration/impact design, meeting the high reliability requirements of continuous production in process industries.

concluding summary

The P0972ZA FCM100E module integrates high-speed conversion, dual rate compatibility, redundant safety, fiber optic anti-interference, and hot swappable maintenance. It is the core communication hub connecting the control layer and field I/O layer in Foxboro DCS system, providing stable, efficient, and highly reliable fieldbus communication solutions for process industries such as petroleum, chemical, and power.

P0972ZA FCM100E Product imag
