IMASI13 Analog Input Module

IMASI13 Analog Input Module

Product Details Introduction

Application areas of IMASI13 analog input module products (15 items)

1. Thermal power plant: adapted to ABB Harmony system, collecting temperature signals of turbine thermal resistance (RTD), 24 bit resolution ensures accurate feedback of unit operating parameters, and provides data support for regulation.

2. Petroleum refining: Receive 4-20mA signals from pressure transmitters in catalytic cracking units, with independent channel isolation design to resist strong electromagnetic interference and ensure stable collection of process pressure data.

3. Chemical Industrial Park: Collect temperature and pH sensor signals from reaction kettle thermocouples (K-type), automatically complete cold end compensation, and provide accurate data sources for process optimization.

4. Water treatment plant: Capture simulated signals of sedimentation tank liquid level, turbidity, and dissolved oxygen, support -100 to+100mV signal input, and adapt to various water quality sensor requirements.

5. Metallurgical factory: Collect temperature signals of blast furnace wall resistance, adapt to high temperature conditions with wide temperature working characteristics, and provide real-time feedback of furnace body thermal state data to avoid safety risks.

6. New energy photovoltaics: Receive analog signals of inverter output current and voltage, quickly complete A/D conversion, and provide accurate data for energy efficiency analysis of photovoltaic power plants.

7. Shipbuilding industry: Tolerant to high humidity salt spray environment, collects oil pressure and water temperature signals of ship power system, and uses channel isolation technology to ensure reliable data collection under harsh working conditions.

8. Pharmaceutical workshop: Collect simulated signals of fermentation tank temperature, pressure, and stirring speed to meet the requirements of GMP standards for accurate traceability of production process data.

9. Food processing: Receive steam pressure and temperature signals from the sterilization kettle, upload them in real-time to the control system, and ensure that the sterilization process parameters comply with food safety regulations.

10. Intelligent buildings: Collect 0-10V signals from HVAC system temperature and humidity sensors to provide real-time environmental parameter support for building energy-saving regulation.

11. Rail transit: Collect simulated signals of train brake system oil pressure and brake pad temperature, quickly feedback abnormal data, and ensure driving safety.

12. Laboratory research: Suitable for various experimental equipment, collecting small voltage (mV level) and current signals, with high-precision conversion capability to meet the precise measurement needs of experimental data.

13. Rubber products factory: Collect temperature and pressure simulation signals inside the vulcanizing machine chamber, automatically complete engineering unit conversion, and provide data basis for optimizing the vulcanization process.

14. Municipal heating: Collect temperature and pressure signals of the supply and return water in the heating pipeline, monitor the operation status of the pipeline network in real time, and assist in precise control of the heating system.

15. Aerospace ground testing: Collect temperature and stress simulation signals during the testing process of aircraft components, ensuring high reliability and accurate and effective testing data.

IMASI13 Product imag
