VME-HDD-4G Single Slot Floppy/Hard Disk Module

VME-HDD-4G Single Slot Floppy/Hard Disk Module

Product Details Introduction

Application Fields of VME-HD-4G Single Slot Floppy/Hard Disk Module

The VME-HDD-4G single slot floppy disk/hard disk module is compatible with the VME bus standard and designed with a 6U European card specification. It integrates 4G hard disk and floppy disk storage units and has the ability to adapt to a wide temperature range of -40 ° C to+85 ° C and resist vibration electromagnetic interference. It can stably store operating systems, control programs, and real-time data, and is suitable for various embedded and industrial critical task scenarios. The specific applications are as follows:

1. National defense and military radar system: stores radar signal preprocessing programs and target tracking data, adapts to extreme battlefield environments, and ensures continuous operation of the system.

2. Nuclear submarine control system: As an embedded storage core, it stores power control programs and navigation logs, and adapts to underwater closed conditions with high reliability.

3. Substation automation device: stores voltage and current sampling algorithms and protection logic programs, synchronously retains operation and maintenance historical data, and supports stable control of the power grid.

4. Aircraft engine test bench: Record multidimensional parameters such as speed and temperature during the testing process, store test firmware, ensure data traceability and stable program calling.

5. Main battle tank fire control system: adapted to the vibration environment of the vehicle, stores aiming control programs and trajectory parameters, and realizes fast command reading and response.

6. Medical radiotherapy equipment: stores radiotherapy dose control programs and patient diagnosis and treatment data, meeting the high stability and data security requirements of medical equipment.

7. Wind power generation measurement and control terminal: Save the wind turbine pitch control algorithm and operation log, withstand outdoor high and low temperature, strong electromagnetic interference environment.

8. High speed train control center equipment: stores train dispatch instruction programs and location tracking data, and relies on VME bus to achieve multi module collaborative communication.

9. Industrial mass spectrometer: stores detection calibration programs and sample analysis data to ensure accurate instrument operation and traceability of experimental results.

10. Shipborne communication and command system: adapted to the high humidity salt spray environment of the ocean, storing communication protocols and command and dispatch programs, supporting the collaborative work of shipborne equipment.

11. Nuclear industry measurement and control equipment: stores radiation monitoring programs and data recording firmware, has anti-interference capabilities, and is suitable for special working conditions of nuclear facilities.

12. Precision machine tool CNC system: Save complex machining trajectory programs and tool compensation parameters to ensure continuous high-precision operation of the machine tool.

13. Air defense warning system: stores target recognition algorithms and warning linkage programs, quickly reads data to support real-time response, and adapts to military control requirements.

14. Petroleum exploration logging equipment: records downhole pressure, rock formation data, and detection programs, withstands high temperature and high pressure conditions, and ensures complete storage of exploration data.

15. Old VME system upgrade: As a compatible storage spare, it replaces the original faulty module, retains historical programs and data, and reduces system upgrade costs.

Note: The core advantages of the product are VME bus compatibility, industrial grade wide temperature stability, and dual storage unit redundancy design. It can be adapted to systems such as VxWorks and Linux, meeting the data security and long-term operation requirements of critical task scenarios.

VME-HDD-4G Product imag

VME-HDD-4G  ontroller Module
