Product Details Introduction

Core points of Digital Electronics Meter R8240

This model is the AdvantEST precision digital electrostatic meter/electronic meter, which focuses on low current/high impedance voltage measurement and is suitable for high-precision testing scenarios such as semiconductors and electronic components. The 15 simplified points are as follows:

Brand model: AdvantEST R8240, desktop precision digital electronic meter, core used for low current and high impedance voltage measurement.

Measurement type: Supports DC voltage and DC current measurement, suitable for ultra-high impedance scenarios such as semiconductor device leakage current testing.

Voltage range: covering three levels of 200mV, 2V, and 20V, meeting the requirements of high-precision voltage testing.

Current range: including 200pA, 2nA, 20nA, 200nA, 2 μ A, 20 μ A, 200 μ A, 2mA, 20mA multiple levels, suitable for microcurrent measurement.

Measurement method: Adopting integral measurement method to ensure the stability and accuracy of low current measurement.

Product Features

Input interface: Configure TRIAXIAL triaxial connectors to reduce external interference and ensure measurement accuracy.

Interface communication: Standard GPIB interface, supporting remote control and data transmission, compatible with automated testing systems.

Display function: Clear numerical display, intuitive reading of measurement data, support for basic functions such as data retention.

Anti interference design: high input impedance, effectively suppressing external electromagnetic interference, suitable for high-precision measurement environments in laboratories.

Data collection: It can be combined with dedicated software to achieve timed and quantitative data collection, supporting up to 200000 continuous data collection.

Adaptation and Application

System compatibility: compatible with Windows system, data can be imported into Excel through software for easy data processing and analysis.

Semiconductor testing: used for testing parameters such as leakage current and reverse current of diodes, transistors, and other devices.

Electronic components: Suitable for measuring insulation resistance and leakage current of capacitors, resistors, and other components.

Material testing: used for measuring surface resistance, volume resistance, and other parameters of insulation materials.

Laboratory research: Suitable for high-precision low current/high impedance measurement experiments in fields such as physics and electronics.

R8240 Product imag
