Product Details Introduction

ME-MAX/NEF/QUINT20A Interface Filter Product Features and Application Fields

ME-MAX/NEF/QUINT20A is an industrial grade interface filter designed specifically for QUINT series power supplies and industrial equipment interfaces. Its core functions include electromagnetic interference filtering and signal purification, with high adaptability and reliable protection. It is a key component for ensuring industrial interface stability. Its core features and application areas are as follows:

Core product features

Efficient filtering and signal purification: Integrated with GDT+MOV cooperative surge protection circuit, it can accurately filter electromagnetic interference and peak pulses in power and signal lines, suppress common mode and differential mode interference, ensure the stability and integrity of interface signal transmission, and avoid interference causing equipment misoperation.

High compatibility and safety protection: rated current of 20A, compatible with ME-MAX/NEF series interfaces and QUINT power output terminals, compatible with multiple industrial interface specifications. Built in overcurrent protection mechanism, combined with PCB three proof paint process, excellent protection performance, isolation voltage standard, avoiding interface burnout or equipment damage.

Industrial grade weather resistance, stable and reliable: Suitable for working environments with a wide temperature range of -40 ℃~70 ℃, it can withstand industrial scene vibrations, severe fluctuations in temperature and humidity, and corrosive gases. It can maintain stable filtering performance even under extreme working conditions, meeting long-term continuous operation requirements.

Convenient installation, efficient operation and maintenance: adopting a compact structure design, supporting 35mm standard DIN rail installation, without occupying too much control cabinet space. The interface is designed to prevent accidental insertion, with convenient wiring that can quickly connect with power supplies and industrial control equipment. There is no need for frequent maintenance in the later stage, reducing operation and maintenance costs.

Core application areas

Widely used in industrial automation control systems, power measurement and control equipment, metallurgical and chemical production lines and other fields, it is specially designed to match the QUINT series power supply, adapt to the signal interface and power interface of PLC, sensors, transmitters and other equipment, effectively enhance the system's anti-interference ability, and ensure the stable operation of equipment in complex electromagnetic environments.

ME-MAX/NEF/QUINT20A Product imag
