KSTE-KS-KR-2K Printed Circuit Board

KSTE-KS-KR-2K Printed Circuit Board

Product Details Introduction

Characteristics and application areas of KSTE-KS-KR-2K printed circuit board products

KSTE-KS-KR-2K is an industrial grade printed circuit board (PCB) under the Schleicher brand. As a core spare part for industrial control equipment, it focuses on high reliability and precise signal transmission, adapting to the circuit control requirements of harsh industrial scenarios. Its core features and application areas are as follows:

Core product features

High precision process, stable performance: adopting precision circuit design, minimum line width ≥ 0.2mm, inner layer solder pads ≥ 0.5mm, outer layer solder pads ≥ 0.8mm, aperture tolerance controlled within 0.05mm, ensuring precise signal transmission without interference, anti click strength of over 1 million times, suitable for long-term high-frequency working conditions.

Industrial grade material, good weather resistance: epoxy resin (EP) base material and glass fiber cloth based reinforcement material are selected, with a flame retardant grade of V0, excellent insulation performance and anti-aging capability. Suitable for a wide temperature working environment, able to withstand temperature and humidity fluctuations and electromagnetic interference in industrial scenarios, with outstanding stability.

Optimized structural design, reliable conductivity: Adopting through-hole metallization technology, the hole wall coverage is high, the conductivity resistance is low, ensuring high current transmission and heat dissipation efficiency, and avoiding performance degradation caused by heat generation. Double sided circuit layout, balancing design complexity and cost, suitable for multi component integrated installation requirements.

Industrial control adaptation, strong universality: As a standard industrial control spare part, it can seamlessly adapt to Schleicher series industrial control equipment and Schneider Electric related systems, with precise matching of mechanical interfaces and electrical parameters, facilitating equipment maintenance, replacement, and upgrading, reducing operation and maintenance costs.

Core application areas

Mainly used in ship semiconductor industrial control equipment, industrial automation control systems, precision measurement and control instruments and other scenarios, as the core circuit carrier, supporting equipment signal processing, instruction transmission and power control, and adapting to the operational requirements of harsh industrial fields such as ships, metallurgy, and chemical engineering.

KSTE-KS-KR-2K  Product imag
