MD5-HD14 stepper motor driver

MD5-HD14 stepper motor driver

Product Details Introduction

Characteristics and application areas of MD5-HD14 stepper motor driver products

MD5-HD14 is a DC type 5-phase stepper motor driver launched by Autonex, which focuses on low-speed, high-precision, and low vibration control. It is suitable for the power needs of small automation equipment and is a cost-effective choice for segmented driving scenarios. Its core features and application areas are as follows:

Core product features

Segmented drive, precise and stable: supports high subdivision control, can achieve low-speed rotation without shaking, greatly improve positioning accuracy and smooth operation, avoid step loss and resonance problems of stepper motors, and adapt to scenarios with strict requirements for motion accuracy.

Parameter adaptation, strong compatibility: adopting DC power supply design, rated output current of 1.4A/phase, can accurately match the corresponding power of 5-phase stepper motor, supports pulse/direction control mode, and seamlessly connects with various PLCs and motion controllers.

Industrial grade protection, stable and durable: Built in overcurrent and overheating protection functions, automatically cutting off the drive circuit in case of failure to avoid damage to the motor and driver. Excellent resistance to electromagnetic interference, able to adapt to temperature, humidity, and electromagnetic fluctuations in conventional industrial control environments.

Compact design, easy operation and maintenance: The body structure is compact and supports embedded installation, saving internal space of the device. Equipped with clear status indicator lights, real-time feedback on operation and fault status, simple parameter adjustment, easy to quickly debug and maintain in the later stage.

Core application areas

Widely used in small CNC equipment, automation instruments, precision positioning platforms, textile machinery, electronic component assembly equipment and other scenarios, it adapts to working conditions that require low-speed smooth operation and high-precision positioning, providing reliable power drive and motion control support for equipment.

MD5-HD14 Product imag

MD5-HD14 ontroller Module
