E3-1584 Printed Circuit Board

E3-1584 Printed Circuit Board

Product Details Introduction

1. Basic structure of PCB

E3-1584 is a finished PCB that typically includes the following parts:

Substrate

The main material is insulation material (such as epoxy glass cloth laminated board FR-4).

Plays a role in supporting electronic components and circuits.

Conductive layer (Copper Traces)

The copper wire path formed by etching on the substrate is used to connect various components.

Both the inner layer and the surface may have circuits, and multi-layer PCBs can achieve complex circuit interconnections.

Pads&Vias

The component soldering point is called a solder pad.

Vias are used for electrical connections between the upper and lower layers of PCB circuits.

electronic component

This may include resistors, capacitors, diodes, transistors, integrated circuit chips, etc.

These components combine to perform specific functions such as signal processing, control logic, or voltage regulation.

2. Functions of PCB

E3-1584 typically undertakes the following tasks in the system:

signal processing

Receive input signals from sensors, switches, or other circuits.

Amplify, filter, or logically judge signals.

control function

According to the system logic, output control signals to actuators, relays, or indicator lights.

Can be used as part of the control panel for industrial equipment operation.

interface functionality

Provide power input interface and allocate voltage to each component.

Provide communication or signal interfaces to interact with other parts of the system.

E3-1584 Product imag

E3-1584 ontroller Module
