1769-L35E controller

1769-L35E controller

Product Details Introduction

Product Features of 1769-L35E Controller

1769-L35E is a Rockwell Allen Bradley brand CompactLogix series programmable controller (PAC) designed specifically for medium-sized industrial automation scenarios. It integrates powerful control, communication, and expansion capabilities and is suitable for various fields such as packaging machinery, material handling, and water treatment. Its core features are as follows:

1. High performance core processing

Equipped with a 32-bit Intel processor, the Boolean instruction execution speed reaches 0.22 µ s/instruction, with 2MB of built-in user memory, supporting complex logic control, PID regulation, and mathematical operations to meet real-time control requirements.

2. Dual port Ethernet communication

Integrated dual RJ45 EtherNet/IP ports, supporting 10/100Mbps rates and linear topology cascading, native compatibility with CIP Sync clock synchronization and CIP Motion protocol, simplifying networking and reducing costs.

3. Multi axis motion control capability

Supports up to 8-axis integrated motion control, which can achieve multi axis coordination functions such as electronic cam, flying shear, and chasing shear. It can be directly adapted to servo systems without the need for additional motion controllers.

4. Flexible I/O expansion capability

Supports up to 16 local 1769 series I/O modules (8 on each side), compatible with various modules such as digital, analog, temperature, etc. Remote I/O can be extended through EtherNet/IP to build a distributed architecture.

5. Multi language programming compatibility

Compatible with Studio 5000 programming environment, fully supports IEC 61131-3 standard language, including ladder diagrams, functional block diagrams, structured text, etc., providing online editing and diagnostic tools to improve development efficiency.

6. Reliable data storage guarantee

Built in non-volatile memory ensures that programs and critical data are not lost after power failure. It supports optional CF card expansion storage and can achieve program backup, recovery, and firmware upgrades through USB or SD card.

7. Industrial grade environmental adaptation

The working temperature range is 0 ℃~60 ℃, the protection level is IP20, and it can withstand 95% humidity (can condense). It has good anti-interference ability and is suitable for various harsh environments in industrial sites.

1769-L35E Product imag
