853-064887-002 RF source unit

853-064887-002 RF source unit

Product Details Introduction

853-064887-002 RF Source Unit Product Description

853-064887-002 is an industrial grade RF source unit, positioned as the core component for generating and outputting RF signals. It can stably output RF signals in specific frequency bands and has the characteristics of precise and controllable frequency, high spectral purity, and strong environmental adaptability. It is widely suitable for RF testing, communication system debugging, and scientific research experiments. The core information is as follows:

1、 Core technical characteristics

-Broadband signal output: It is speculated to cover the commonly used RF frequency band of 10MHz~3GHz, support precise adjustment of signal frequency, and have a resolution of up to 0.1Hz, which can adapt to the RF signal requirements of different scenarios;

-High frequency spectrum purity and stability: It has excellent single sideband phase noise characteristics, with phase noise better than -70dBc/Hz at 10kHz frequency offset across the entire frequency band. The time base aging rate is low, and the temperature stability is strong, ensuring the purity and consistency of the output signal;

-Flexible power adjustment: Wide output power range, adjustable from -127dBm to+20dBm, power resolution of 0.1dB, high accuracy, can accurately match signal strength according to testing needs;

-Multi modulation mode support: compatible with various modulation methods such as FM, AM, and pulse modulation, with controllable modulation rate and depth, capable of generating diverse RF signals and adapting to complex testing scenarios;

-Industrial grade reliable design: compliant with industrial electromagnetic compatibility specifications, suitable for working temperature range of 0 ℃~40 ℃, with overload protection, overheating protection and reverse power protection functions, and can operate stably for a long time;

-Convenient control and integration: Supports analog ports, RS232/RS485 and other control methods, provides standard programmable commands, can achieve local and remote control, and is easy to integrate into automated testing systems.

2、 Core application areas

-RF testing of electronic devices: suitable for performance testing of communication terminals, RF modules, antennas and other electronic devices, providing standard RF signal sources to verify key indicators such as device reception sensitivity and anti-interference ability;

-Communication system debugging: research and debugging of wireless communication base stations, satellite communication systems and other equipment, simulating communication signals of different frequency bands and modulation modes to ensure system communication quality;

-Research and laboratory scenarios: used for research projects such as RF technology research and electromagnetic compatibility experiments, providing stable and controllable RF signals and reliable data support for experimental research;

-Industrial RF equipment matching: It can serve as the core signal generation component for industrial RF heating, RFID and other equipment, ensuring the stable performance of equipment RF.

853-064887-002 Product imag
